Teltonika Teltonika US Power Supply, 24W

Teltonika Teltonika US Power Supply, 24W

$19.99
$19.99
En vente Épuisé

En rupture de stock

For a custom quote please email sales@ziestech.com

US POWER SUPPLY, 24W PR3P2US3

TECHNICAL DATA

  • GENERAL

  • Input voltage

    100 – 240 VAC

  • Input frequency

    50 / 60 Hz

  • Input current

    0.6 A

  • Input connector

    US (Type A)

  • Output voltage

    12 VDC

  • Output current

    2.0 A

  • Output connector

    4-pin, 3 mm pitch

  • ADDITIONAL

    US POWER SUPPLY, 24W

  • Input voltage range

    90 – 264 VAC

  • Input frequency range

    47 – 63 Hz

  • Maximum input inrush current

    40 A

  • Output voltage maximum deviation

    11.4 – 12.6 VDC

  • Short circuit protection

    ✓

  • HIPOT (dielectric withstand test)

    Primary to Secondary: 3000 VAC

  • MTBF

    50000 h

  • Certification

    47 CFR FCC part 15 subpart B, 10-1-2016, ANSI C63.4:2014, IEC 62321-7-1:2015, IEC 62321-6:2015, IEC 62321-5:2013, IEC 62321-4:2013, IEC 62321:2008 Annex C, UL 60950-1, CSA C22.2 No 60950-1-03

Afficher tous les détails
