The Lenovo ThinkSystem 440-16e SAS/SATA 12Gb HBA is a high performance PCIe 4.0 host bus adapters for external storage connectivity in ThinkSystem servers. The adapter provides four x4 external mini-SAS HD connectors with 16 lanes of 12 Gbps SAS.
PCIe 4.0 x8 host interface
12Gbps SAS/SATA host bus adapter, based on the Broadcom SAS3816 IOC design
PCI low profile, half-length form factor
16x 12Gbps SAS/SATA ports for connectivity to 16x internal drives
Non-RAID (JBOD mode) support for SAS and SATA HDDs and SSDs
Connectivity for up to 1024 external SAS or SATA drives
Up to 12 Gbps throughput per port: Supports 12, 6, or 3 Gbps SAS speeds, Supports 6 or 3 Gbps SATA speeds
Four external x4 HD Mini-SAS connectors (SFF-8644)
Support for external storage systems and tape backup units
High performance architecture with very deep queue depth
